HO scale model railroad crossing signals
Operating grade crossing signals from Tomar Industries, Walthers and NJ International in 1:87 HO scale
HO grade crossing scenic details from Blair Line and Woodland Scenics
|
Protect your model trains from careless motorists and pedestrians with operating crossing signals. Flashing crossbucks and movable crossing arms will liven up your layout and grab your visitors' attention.
Crossing signals in other scales >>> [O scale]
[N scale]
Walthers single lane over-the-road HO Crossing signal
• 949-4331 modern cantilever signal
• Eight LEDs per signal, 4 forward, 4 back
• Mast is 3.0 inches tall (76mm)
• Bridge extends 2.5 in. (63mm) from mast
• Detailed plastic casting
• One signal per package
Flasher circuit with resistors sold separately.
|
|
949-4331, Walthers photo
|
SceneMaster™ HO crossing signals with operating LEDs
• 949-4333 lighted crossbucks signals
• Two LEDs per signal, front side only
• Detailed plastic casting
• Two signals per package
• Where the crossing is only visible from one side of the layout, you can place both signals facing toward the visitor side so all LEDs will be visible.
Flasher circuit with resistors sold separately.
|
|
949-4333 signals
|
Walthers photos
|
Tomar Industries HO scale crossing signals
Tomar Industries H-862 HO scale
• Two signals per package
• LEDs on front and back, 4 per signal
• Height: 2.2 inches base to top of mast
• 0.28 inch dia. lamp targets
• Includes numeral decals to indicate 1, 2 or 3 tracks
• Current limiting resistors included but are not attached.
Flasher circuit sold separately.
How to connect resistors to Tomar crossing signals, click here.
|
|
Tomar H862 front
|
Tomar H862 back
|
Tomar H-863 crossing signals with movable gate arms, HO scale
• Two signals per package
• LEDs on front and back, 4 per signal
• Height: 2.2 inches base to top of mast
• 0.28 inch dia. lamp targets
• Current limiting resistors included but are not attached.
MRX3 controller circuit sold separately.
|
|
H863 front
|
H863 back
|
- Side-by-side comparison of NJI and Tomar HO scale crossing gates (right). The NJI signal has a taller pole.
The Tomar signals have larger crossbucks and lamp targets, and the gate arm is longer. Gate arm can be easily cut to desired length.
Tomar supplies red/white and black/white decals that the user trims to size and applies to the gate arm.
Or, the gate arms can be painted.
|
NJI 1165 vs. Tomar H-863
|
NJ International HO scale signals
NJ International HO scale
• Two signals per package
• LEDs on front and back, 4 per signal
• Bar style arms, red stripes
• Arm length: 2.3 inches pivot to tip
• Height: 2.5 inches base to top of mast
• 0.22 inch dia. lamp targets
• Modern pedestal style base
• Current limiting resistors included
|
|
NJI 1164 front
|
NJI 1164 back
|
|
Flasher circuit and motors sold separately, see crossing gate installation examples for more info.
|
NJ International crossing signals are out of production.
If NJI resumes production we will have them available again at that time.
|
NJ International 1095 HO scale
• Two signals per package
• LEDs on front and back, 4 per signal
• Height: 2.1 inches (53mm) base to top of pole
• 0.22 inch (5.6mm) dia. lamp targets
• Current limiting resistors are attached
Flasher circuit sold separately
|
|
NJI 1095 front
|
NJI 1095 back
|
HO grade crossing scenic accessories
• 'Steel' grade crossing road panels Woodland Scenics C1148
• Glue to straight track, suitable for code 70, 83 and 100 rail
• Two-lane street, 2.6 inches wide (66mm)
• Two sets per package, for two crossings or for one double-wide crossing
Installation instructions [pdf]
|
|
|
|
Blair Line laser-cut wood grade crossings
For HO scale curved track, choose radius:
- BL 126, 17-19 inch radius
- BL 111, 19-21 inch radius
- BL 127, 21-23 inch radius
- BL 128, 23-25 inch radius
• Two-lane street
• Etched planks and bolt holes, ready for paint or stain
• Two complete sets per package
|
HO curve track road crossings
Blair Line photos
Choose track radius:
|
Blair Line laser-cut wood grade crossing
For HO scale straight track
- BL 165, not stained
- BL 115, pre-stained
• For two-lane street, 3.56 in. (9cm) wide
• Two complete sets per package
|
|
straight HO road crossing, not stained
HO road crossing, pre-stained
|
Atlas/BLMA HO scale electrical equipment box
Often seen at grade crossing or track signals
Lift hooks to be applied separately
4310 small electrical box
- Fits in a narrow space
- 0.92 x 0.34 inches, 0.94 in. tall
|
|
4310 small electrical box
Atlas/BLMA photo
|
