Model Railroad Reversing Tracks How to automate reverse loops and wyes on your two-rail layout, whether DC, DCC or AC powered

Two-rail model train layouts require special treatment of reversing tracks. Wiring reversing tracks (reverse loops or wyes) is not complicated, but it must be done correctly.

[Click here to review reverse loop fundamentals]

Reversing tracks can be of different forms. Choose a track plan below that best represents the situation on your layout.

Wye track

Dog bone layout with single main line

Single loop

Dog bone, double track main line with cross-overs

 MREV Track Polarity Controller

The MREV circuit module is used for controlling track polarity on two-rail model railroad layouts that have one or more reversing loops or wyes. It is compatible with DC, AC and DCC track power systems.   Can be used on layouts with multiple cab control block wiring.   The MREV has two DPDT reversing relays, each capable of switching up to 8 amps. Control inputs come from train detectors installed in or beside the track. Train detectors are sold separately.   An accessory power supply of 9 to 15 volts AC or DC is required.   Click here to download the MREV instructions [pdf] The MREV track polarity controller may be purchased separately or as part of a system package. To see packages, click on one of the layout plans above. MREV  $32.50
